HYDRA-Dry Ultra High Purity Pressure Transducer - Model HD
Brand: WIKA Instruments Ltd.The digital indicator model HYDRA-Indicator offers a unique solution for a local display of the process pressure at the transducer model HYDRA-Dry.
With this HYDRA-indicator, which has been specially designed for the UHP market, a signal and freely adjustable switch points can be transmitted simultaneously. Its scale can be fully adjusted directly on site without master instrument.
Features- Patented double diaphragm.
- Completely dry: non-metallic ceramic sensor; no fill fluid.
- Perfluoroalkoxy (PFA) wetted parts.
- Transducer is 270° rotatable even after installation.
- Ingress protection IP 67.
- Optional: Model HYDRA-Indicator as panel mount or integrated indicator.
Specifications
Wetted Materials
- PFA or TFM (modified PTFE), no transfer-fluid
Material of Construction
- PVDF, EPDM, FPM/FKM
Pressure Range
- 0 to 6 bar (0 to 100 ps, 0 to 600 kPa)
Process Connection
- Iin-line 3/8" flare, ½" flare, ¾" flare, 1" flare, 1 ¼" flare
- Dead-end ¼" flare, 3/8" flare, ½" flare
- Dead-end ¼ NPT female
Accuracy
- ≤ 0.5% of Span
Environmental Protection
- IP67
Certifications & Approvals
- CE
